Z Steps (Ap)

Definition

The Z Step (Ap) is the increment in the Z-axis between each machining pass. It divides the total cutting depth into multiple passes. If the Z Step value exceeds the tool's maximum allowable depth per pass, a warning message is displayed.


Z Step (Ap) for Slotting


Z Step (Ap) for Chamfering


Z Step (Ap) for Taper Cutting


Z Step (Ap) for Mouse Facing


Z Step (Ap) for Profile Cutting

Depth input is also required.


Z Step (Ap) for Text Marking

Depth input is also required.


Z Step (Ap) for Roughing Rework / Facing Roughing / Pocket - Shape


Z Step (Ap) for Finish Contour - Shape


Z Step (Ap) for Finishing

To compute the Z Step:

  1. Add the Z Step (Ap) value needed

  2. If required, choose Yes for the Constant Scallop

  3. Add the Scallop value


Z Step (Ap) for Finish Reworking

To compute the Z Step:

  1. Add the Z Step (Ap) value needed

  2. If required, choose Yes for the Constant Scallop

  3. Add the Scallop value
