Frontal Leadin, Leadin Distance and Finishing Stock Allowance

Cycles: End Facing

Definition


Frontal Leadin: avoids the tool to lead in vertically, hence limiting the insert wear. The tool entry is from the front.

cycle. The entry is now from the front.

See the video as from 01:23

End Facing-20250218-045609.png

Leadin Distance: this value is the vertical distance between the stock and the start of the frontal pass also contributing to limiting the tool wear.

Finishing Stock Allowance

Leaves a stock allowance to be reworked by the finishing pass.

In the case where there is a taper due to the insert shape on a Frontal leadin, a Finishing stock allowance can be input to solve this issue. Only the last toolpath is computed to machine the face completely vertical.

See the video for an example.
