Mini & Maxi angle of reworking

• Vertical and Horizontal cycles have been merged and renamed to Slope cycles (Slope //Plane, Slope Equidistant, Slope Z Level) due to new angle parameters.

• The reworking toolpaths are now processed according to ranges of angles. For example, reworking areas with small angle but avoiding flat faces is possible!

• Calculations of angles are simplified and new explicit icons are available.

Mini angle of reworking

The mini and maxi angle of reworking define the set of angles for which toolpaths will be generated for zones between these two angles.

This provides the possibility to machine zones while avoiding completely vertical or horizontal surfaces.

For example, angles set to 50 and 89 degrees will only machine the surfaces which are sloped within these angles and the value of 89 degree for the maxi angle of reworking will completely avoid flat surfaces.

Maxi angle of reworking
