Curve

Design a Curve

Open the wireframe menu and select the curve icon. Click on a minimum of two positions on the plane to define the path of the curve.

	Closed Curve	After creating an open curve, click the "Close Curve" function in the curve menu to connect the end point to the starting point, forming a closed loop.
	Start in tangency	This function allows you to define a smooth, continuous connection at the starting point of the curve. You can specify the tangent direction for a seamless transition from another curve or line segment.
	End in tangency	Similar to "Start in Tangency," but applied to the ending point of the curve. This ensures a smooth flow when connecting to other elements.

Edit a Curve

These functions are accessible through the "Drawing Finishes" section of the wireframe menu and allow for further manipulation of your curves:

	Trim/Extend	Cut or lengthen the curve by specifying new end points.
	Divide	Split the curve into multiple segments at specific points.
	Merge	Combine two or more selected curve segments into a single curve.
	Convert to Arc/Segment	Change the type of curve segment between a smooth arc and a straight line segment.

▶️ The included video demonstrates curve creation and editing in an older software version. While the core functionalities remain the same, the menus and their locations might have changed in newer releases.
