Presentation

The General toolbar is a set of commands which are common to all the environments and products of GO2cam.

This toolbar is accessible in the top right hand side corner.

List of Commands

Update

Updating of the geometry and the machining cycles if changes are done.


In case of changes in the machining cycles, GO2cam displays an orange balloon to show that an update is necessary. Changes can be move of operations, change of tool, modification of any parameter value, etc. No change in relation with geometry is shown here!

 Control

This device enables to control the characteristics of your part: it displays distances and angles between elements, the coordinates of elements and other characteristics (radius values, length, etc.). The control is also able to measure and to display topologic information about solids.

Furthermore, this command gives the ability to define tolerances on the solid geometry.

More information: The Control

Management of Attributes

The attributes used currently are defined in the pallet: the color, the line type, the line thickness and the layer number.

In this command you can also filter elements by type of attribute, for example you can choose to see only elements with red color. You can also recover existing attributes by clicking on an element with the pipette.

Multiple selection is also possible with a re-organised and improved dialog box.

 Undo

Cancellation of the last actions done. This command allows multiple use.

Click here for more details.

Redo

Command linked to the Undo command.

Click here for more details.

Wizard

By clicking any element of geometry, the wizard enables to activate the corresponding command without selecting it. By clicking a machining cycle, it enables to recover some technical data or cycle references as a shortcut would do.

Description here: Wizard

Eraser

Deletion of the elements shown, one by one or within a selection box: right button of the mouse to validate.

Zoom

This is the most useful zoom command: you can detail an area of the part by making a window around it.

Framing

Automatic positioning in a view extending the visualization to all the elements of the drawing.

Details

This command enables to show or not some elements, which are not always necessary, according to the context. The pink color for the unconstrained elements is displayed in relation with this command; in machining mode you can hide the symbols of techno commands and the rapid toolpaths.

Change of View

Clicking on the icon activates alternatively several views: current view, perspective view, front view. You can choose these views in Tools/Options/Graphic Window.
