1. Overview
The NC (Numerical Control) validation process integrates real-time machine control with digital simulation to ensure that machining operations are safe, efficient, and optimized—directly from the NC program. By replicating actual machine behavior, this workflow verifies toolpaths, material removal, and collision avoidance before physical production begins.
2. Prerequisites
Before starting the validation process, ensure the following prerequisites are met:
-
A complete project file including part, toolpaths, machine files, and fixture setup.
-
The NC Code file generated from the process is available.
-
NC control installation for the current version of GO2cam.
3. Process Workflow
Step 1: Load the project and machine setup
-
Open the project file with the part, machine, and fixture setup.
-
Confirm all geometry, tooling, and setup parameters are configured.
-
This prepares the simulation environment with accurate physical context.
Step 2: Load the NC Code File
-
Load the NC code file into the system.
-
This initializes the machine controller (e.g., FANUC), ensuring:
-
Accurate motion logic
-
Proper axis limits
-
Controller syntax fidelity
-
Step 3: Launch NC Control Module
-
Open the NC Control module.
-
Replace standard MTE simulation controls with a real-time NC controller interface.
-
The system executes G-code exactly as the physical machine does, enabling authentic code-level validation.
Step 4: NC Code Editing and Validation
-
Use the NC Code Editor (Camparser) to:
-
View and directly edit G-code
-
Apply changes and instantly observe effects in the 3D simulation
-
-
This live connection between editor and simulation enables true NC code validation without external reruns or exports.
Step 5: Core Simulation Functions
The NC Control module performs comprehensive validation through five key stages:
|
Stage |
Function |
Description |
|
1 |
G-code Interpretation |
The system reads and interprets each command line from the NC program. |
|
2 |
Toolpath Simulation |
The programmed tool motion is visualized in real time. |
|
3 |
Material Removal Simulation |
The virtual workpiece updates dynamically as the tool cuts material. |
|
4 |
Collision Detection |
The system checks for collisions between tool, workpiece, and fixtures. |
|
5 |
Visualization & Optimization |
Provides visual feedback to refine cutting strategy and improve efficiency. |
Step 6: Editing and Recomputing NC Code
If adjustments are needed (e.g., adding a spindle movement):
-
Unlock the Camparser editor.
-
Insert or modify G-code/M-code commands.
-
Lock the Camparser.
-
Click Execute (green button) to apply updates.
-
Instantly verify the changes in the 3D simulation.
4. Final Approval and Release
Once the simulation confirms no collisions, correct final geometry, and optimized toolpaths, the NC program is validated and ready for safe transfer to the CNC machine for production.
-
Always verify that the correct machine controller is selected before starting the simulation.
-
For complex parts or multi-axis machines, consider running multiple simulation passes to ensure comprehensive validation.
-
Document any manual code edits for traceability and future reference.
