Solid Creation Menu

Solid Extrusion - Construction of a solid by giving a thickness following a direction to a closed profile.

Revolution - Construction of a revolution solid by giving an angle and a rotation axis.

Extrud Along Path - Construction of a solid defined by a section following a directing profile called backbone.

Lofting - Creation of a solid by lofting between several profiles.

Bounding Box: This is a rectangular shape that encompasses the entire volume of a 3D object.

Rectangular Cuboid - Create a rectangular prism defined by its length, width, and height.

Rectangle - Draws a rectangle defined by 2 points. The 2 points represent a diagonal of the rectangle.

3 Points Rectangle - Draws a rectangle defined by 3 points. The 2 first points represent one side of rectangle; the third point defines the width (or length) of rectangle.

Center Rectangle - Draws a rectangle piloted by its center. Click a point to define the center. Then click a point to define half the length (or width). Click a third point to define half the width (or length).

Cylinder - Create a cylindrical shape defined by its radius and height.

Center Circle – Draw a circle defined by its center and its radius.

2 Points Circle – Circle going through 2 pts defined: by their coordinate, by clicking a point (or intersection or extremity), by tangency.

3 Points Circle – Circle going through 3 pts defined: by their coordinates, by clicking a point (or intersection or extremity) by tangency.

Predefined Circle – Draw a circle by its center and predefined radius.

Sphere - Construction of a solid spherical defined by its radius.

Center Circle – Draw a circle defined by its center and its radius.

2 Points Circle – Circle going through 2 pts defined: by their coordinate, by clicking a point (or intersection or extremity), by tangency.

3 Points Circle – Circle going through 3 pts defined: by their coordinates, by clicking a point (or intersection or extremity) by tangency.

Predefined Circle – Draw a circle by its center and predefined radius.

Cone - Create a conical shape defined by its radius and height.

Center Circle – Draw a circle defined by its center and its radius.

2 Points Circle – Circle going through 2 pts defined: by their coordinate, by clicking a point (or intersection or extremity), by tangency.

3 Points Circle – Circle going through 3 pts defined: by their coordinates, by clicking a point (or intersection or extremity) by tangency.

Predefined Circle – Draw a circle by its center and predefined radius.

Torus - Construction of a solid torus by its outer and inner diameters

Center Circle – Draw a circle defined by its center and its radius.

2 Points Circle – Circle going through 2 pts defined: by their coordinate, by clicking a point (or intersection or extremity), by tangency.

3 Points Circle – Circle going through 3 pts defined: by their coordinates, by clicking a point (or intersection or extremity) by tangency.

Predefined Circle – Draw a circle by its center and predefined radius.
