Solid Modification Menu

Boolean Operation - Perform operations like union (combine objects), intersection (find overlapping parts), or subtraction (remove one object from another).

Union -This Boolean operation combines multiple solids into a single, larger solid.

Subtraction - Subtraction of one or several solids from one another

Intersection - Intersection of a solid with one or several solids

Fillets - Construction of fillet on an edge or on a sequence of tangent edges of a solid.

Fillet with Variable Radius - Creation of a fillet with variable radii.

Chamfer - Construction of chamfer on an edge on a sequence of tangent edges of a solid.

1 Distance Chamfer - Draws a chamfer defined by a distance.

2 Distances Chamfer - Draws a chamfer defined by 2 distances.

1 Distance and 1 Angle Chamfer - Draws a chamfer defined by a horizontal distance and an angle.

Shell - Click on the solid to give a thickness to its walls, it is also possible to open a face clicking on it.

Taper - Addition of a taper on some faces of the solid

Face offset - Offset of one or several faces : click on the faces to modify 1 by 1 then validate with a right-click.

Solid Section - Section of a solid through a plane at a given Z

Separation on Profile - You can cut the solid in 2 solids. Select a set of geometric elements that will be the profile of cut.
